SM-65A

Metal cored wire for welding high tensile steels down to -60°C.

AWS A5.28 E90C-G H4
EN ISO 18276-A: T 55 6 ZMn2Ni M M21 2 H5
EN ISO 9606-1: FM2

Generell beskrivelse:

SM-65A is a 2% Ni-type metal cored seamless wire developed for use with M21 shielding gas. The wire is designed for welding root passes in the short-arc range, as well as for manual and mechanized welding of fillet welds in the spray-arc range. SM-65A is designed to provide high productivity. The seamless wire has a stable welding arc with low spatter and excellent visual bead shape. The wire has a copper-coated surface that results in low wear on wire liners and contact tips. It also ensures reliable wire feeding thanks to the smooth surface and precise roundness, making it suitable for use with long conduit cables. Mechanical properties have been designed for Charpy impact values ≥ 47 joules at −60 °C. Recovery (average): 95%

Typical chemical composition of all-weld-metal:

C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V
0.05	0.36	1.66	0.011	0.005	<0.30	2.10	0.02	<0.01	0.01

Typical mechanical properties of all-weld-metal:

Yield	Tensile	Elongation	Charpy
611 Mpa	679 Mpa	24 %	84V(J)/-60ºC

Diffusible hydrogen content:

≤5 ml/100g (2 ml/100g typisk).

Forpakningsdata:

1,2mm x 5,0kg spool -ArticleNo.: 550461
1,2mm x 12,5kg spool -ArticleNo.: 550457

Approvals:

CE
Pending: DNV-GL, LR .

Reference/date:

SM-65A, English, 20.04.2026.
